ASTM A269 310 Stainless Steel Tubing
1. Standard: ASTM A269, ASME SA269
2. OD Size: 1/2" OD (3.18 mm) -12" OD (127 mm)
3. Wall Thickness: 0.40 mm - 12.70 mm
4. Equivalent: UNS S31000, WNR.1.4841, AISI 310
ASTM A269 310 Stainless Steel Tubing is a high temperature grade with excellent resistance to high temperature oxidation and corrosion. 310 Stainless Steel Tube contains high levels of Chromium (25-28%) and Nickel (19-22%), as well as moderate amounts of Manganese and Silicon. These pipes are often used in high temperature corrosive environments such as heat exchangers, furnace components, and other high temperature applications. We are a 310 SS Pipe supplier with 15+ export experience. We can provide seamless and welded pipes. Contact us for more information and free quotes!
ASTM A269 TP310 Stainless Steel Tube Standard:
-
ASTM A269: Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
-
Grades: 310S, 317, 317L, 321, 321H, 347, 347H, 904L, 254SMO, 253MA, S32550, S32205, S31803, 2507, S31050, S30815, Etc.
-
Available forms for 310: Fittings, Flanges, Forgings, Fasteners, Pipes, Tubes, Plates, Sheets, Strips, Coils, Bars, Round Rods, Etc.
ASTM A269 310 Stainless Steel Tubing Chemical Composition
|
Chemical Composition |
310 |
310S |
|
Carbon |
0.25 max |
0.08 max |
|
Manganese |
2.00 max |
2.00 max |
|
Silicon |
1.50 max |
1.00 max |
|
Phosphorus |
0.045 max |
0.045 max |
|
Sulphur |
0.030 max |
0.030 max |
|
Chromium |
24.00 - 26.00 |
24.00 - 26.00 |
|
Nickel |
19.00 - 22.00 |
19.00 - 22.00 |
| Mo | 0.75 | 0.75 |
Alloy 310 Stainless Steel Seamless Tube:
The manufacturing process of 310 Stainless Steel Seamless Tube involves perforating a solid 310 stainless steel billet, which is then extruded into the desired shape and size. The seamless pipe has no welds on the inner and outer surfaces and can withstand high pressure applications.
AISI 310 Stainless Steel Welded Tube:
Cost Effectiveness: SS310 steel welded pipes are generally more cost effective than seamless pipes as they involve a simpler manufacturing process and are also suitable for large diameter applications.
SS 310 Steel High Temperature Performance
Resists oxidation in continuous service at temperatures up to 1150°C in the absence of reducing sulfur-containing gases. Can be used for intermittent service at temperatures up to 1040°C.
