Alloy 625 Steel Pipe

1. Standard: ASTM B444, ASME SB444, ASTM B474, ASME SB474
2. Sizes: 1/2” to 16”
3. Wall thickness: 0.5 - 20mm
4. Length: Single Random, Double Random & Cut Length

Send Inquiry

Product Introduction

Inconel 625 pipes bring the excellent performance of the alloy to the extreme, becoming an important tool for connecting, transporting and protecting key fluids. Our manufacturers can produce Inconel 625 seamless and welded pipes to meet industry requirements. Contact us market@htpipe.com for more information and a free quote!

AISI 625 Pipe Standard

Standards	ASTM / ASME B622, B619, B626 / SB622, SB619, SB626
Outer Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB
Thickness	0.3mm – 50 mm
Type	Seamless / ERW / Welded Pipes
Schedule	SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Seamless Pipes & Tubes Size	1 / 8″ NB – 24″ NB
ERW Pipes & Tubes Size	1 / 8″ NB – 36″ NB
Length	Single Random, Double Random & Required Length
End	Plain End, Beveled End, Treaded

Contact now

2.4856 Welded Pipe Composition Standard

Grade		C	Mn	Si	Fe	S	Cr	Al-Ti	Ni
625	min.	–	–	–	–	–	20	–	58
625	max.	0.1	0.5	0.5	5	0.015	23	0.4	–

ASME SB444 Alloy 625 Pipe properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Inconel 625	8.4 g/cm3	1350 °C (2460 °F)	Psi – 1,35,000 , MPa – 930	Psi – 75,000 , MPa – 517	42.50%

Why choose Inconel N06625 tube?

Inco 625 pipe Corrosion barrier

The pipe can provide excellent protection for the highly corrosive media (hot concentrated acid, mixed acid, halide solution, caustic alkali, etc.) flowing inside with a relatively thin wall thickness (compared to heavy equipment), significantly reducing material costs and equipment weight. At the same time, it resists the dual erosion of the medium inside the pipe and the external environment.

alloy 625 pipe High temperature and high pressure

The ability to withstand high temperatures (up to about 900°C in oxidizing environments) is better than many stainless steels and ordinary alloy steels in resisting slow deformation (creep) and gradual stress reduction (relaxation). It remains stable in oxygen-containing, carbon-containing high-temperature atmospheres to avoid failure due to wall thinning or embrittlement.

UNS N06625 Pipe Excellent manufacturing and connectivity

Although it has high strength, its good ductility allows it to be formed into complex pipes through processes such as cold bending and hot bending.

Inconel 625 has quite good weldability. Using matching ERNiCrMo-3 welding wire and appropriate processes (such as TIG, MIG), combined with post-weld solution treatment (depending on requirements), high-quality welds with performance close to that of the parent material can be obtained, significantly reducing the risk of intergranular corrosion.

n06625 alloy pipe Long life and low maintenance

Excellent corrosion resistance and high temperature resistance translate into extremely long service life, greatly reducing the frequency and cost of downtime maintenance and pipeline replacement, especially in environments that are difficult to access or costly to repair.

Application of no6625 pipe

Oil and gas: submarine pipelines, downhole tools for acid gas wells.
Chemical equipment: sulfuric acid reactors, phosphoric acid evaporators, pickling equipment.
Nuclear industry: containers and pipelines for nuclear waste treatment systems.
Marine engineering: seawater desalination devices, heat exchangers.
Environmental protection: key components of flue gas desulfurization (FGD) systems.

Alloy 625 Welded Pipes size

Nominal size [inches]	Outside diameter [inches]	Outside diameter [mm]	Wall thickness [inches]	Wall thickness [mm]	Weight [lb/ft]	Weight [kg/m]
1/8	0.405	10.3	0.068	1.73	0.24	0.37
1/4	0.54	13.7	0.088	2.24	0.42	0.84
1/2	0.84	21.3	0.109	2.77	0.85	1.27
3/4	1.05	26.7	0.113	2.87	1.13	1.69
1	1.315	33.4	0.133	3.38	1.68	2.5
1.25	1.66	42.2	0.14	3.56	2.27	3.39
1.5	1.9	48.3	0.145	3.68	2.72	4.05
2	2.375	60.3	0.154	3.91	3.65	5.44
2.5	2.875	73	0.203	5.16	5.79	8.63
3	3.500	88.9	0.216	5.49	7.58	11.29
3.5	4.000	101.6	0.226	5.74	9.11	13.57
4	4.500	114.3	0.237	6.02	10.79	16.07
5	5.563	141.3	0.258	6.55	14.62	21.77
6	6.625	168.3	0.28	7.11	18.97	28.26
8	8.625	219.1	0.322	8.18	28.55	42.55
10	10.75	273	0.365	9.27	40.48	60.31
12	12.75	323.8	0.406	10.31	53.52	79.73
14	14	355.6	0.375	11.13	54.57	94.55
16	16	406.4	0.5	12.7	82.77	123.3
18	18	457	0.562	14.27	104.67	155.8
20	20	508	0.594	15.09	123.11	183.42
24	24	610	0.688	17.48	171.29	255.41
32	32	813	0.688	17.48	230.08	342.91

625 Inconel Pipes pressure

Size	Grade	Maximum internal pressure, ksi
mm	Grade	Maximum internal pressure, ksi
		100°F	200°F	300°F	400°F	500°F	600°F	700°F
1.59 x 0.36	N06625	19.21	19.21	19.02	18.83	18.54	18.15	17.77
3 x 0.5	N06625	940	940	930	921	907	888	869
6 x1	N06625	940	940	930	921	907	888	869
8x1	N06625	681	681	675	668	658	644	630
8x2	N06625	1476	1476	1462	1447	1425	1395	1366
10x1	N06625	534	534	529	524	516	505	494
12x1	N06625	440	440	435	431	424	415	407
16x1	N06625	324	324	321	318	313	307	300
