UNS S31803 Duplex 2205 Plate

S31803 is a duplex stainless steel material widely used in the industrial field. The "duplex" in its name comes from its unique microstructure - ferrite and austenite coexist in a ratio close to 1:1. This structure gives S31803 excellent mechanical properties and corrosion resistance, making it an ideal choice for harsh environments such as petrochemicals, offshore engineering and chemical processing.



ASTM A790 UNS S31803 Plate manufacturer, supplier

With 15+ years in export logistics, HT PIPE stands as a reputable supplier and exporter. Our inventory includes pipes, ASTM A240 S31803 plates, bars, alongside high-quality fittings, flanges, and fasteners. Reach out today for competitive pricing and detailed specifications-no obligation, just expert support.



Physical and Mechanical Properties of uns31803

The density of S31803 is about 7.8 g/cm³, which is between austenitic and ferritic stainless steels. Its room temperature tensile strength is usually more than 620 MPa, and its yield strength can reach 450 MPa, which is significantly higher than 304 or 316L stainless steel. Its elongation is about 25%, combining high strength with good plasticity. At low temperatures (-50°C), its impact toughness remains at a high level, but when used for a long time at high temperatures (over 300°C), care should be taken to avoid embrittlement caused by precipitation of σ phase.



Duplex 2205 Material Chemical Composition

Element	Content (%)
Molybdenum, Mo	2.50-3.50
Manganese, Mn	2.0
Silicon, Si	1.0
Nitrogen, N	0.080-0.20
Iron, Fe	63.75-71.92
Chromium, Cr	21.0-23.0
Nickel, Ni	4.50-6.50
Carbon, C	0.030
Phosphorous, P	0.030
Sulfur, S	0.020



ASTM A240 UNS S31803 Duplex Plate Equivalent Material

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
		BS	En	No	Name
2205 Plate	S31803 / S32205	318S13	-	1.4462	X2CrNiMoN22-5-3	2377	SUS 329J3L



ASME SA 240 UNS S31803 Sheet, Plate & Coil Specifications

Specifications	ASTM A240 / ASME SA240
Thickness	4mm-100mm
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Manufacturers	Jindal, Sail, Outokumpu, Shah Alloys, TISCO, BAOSTEEL, LISCO, JISCO, ZPSS, POSCO

Contact now

Corrosion resistance of 1.4462

The corrosion resistance of S31803 is one of its core advantages. Its pitting resistance equivalent value (PREN) is calculated by the formula PREN = %Cr + 3.3×%Mo + 16×%N, which can reach more than 35, and can resist medium-concentration chloride solutions, acidic media (such as dilute sulfuric acid, acetic acid) and oil and gas environments containing hydrogen sulfide.

Cutting and forming of Duplex UNS S31803

It is recommended to use plasma or laser cutting. When cold forming, higher material strength should be considered, and larger tonnage equipment may be required.



Welding of Alloy 2205 S31803

ER2209 welding materials are preferred, and the interlayer temperature is controlled below 150°C to avoid precipitation of harmful intermetallic phases due to overheating.



Heat treatment of UNS S31803 Plate

Solution treatment needs to be carried out between 1020-1100℃, followed by rapid water cooling to retain the duplex structure.



UNS S31803 Plate Thickness

ASTM A240 UNS S31803 Plate Thickness (mm)	ASTM A240 UNS S31803 Plate Dimensions
1.5	3m x 1.5m
2	3m x 1.5m
3	3m x 1.5m
5	3m x 1.5m / 4m x 2m
6	3m x 1.5m / 4m x 2m / 6m x 2m
8	3m x 1.5m / 4m x 2m / 6m x 2m
10	3m x 1.5m / 4m x 2m / 6m x 2m
12	3m x 1.5m / 4m x 2m / 6m x 2m
15	4m x 2m / 6m x 2m
20	4m x 2m / 6m x 2m



Dimension of SA 240 S31803 Plate

Plate Surface finish	Thickness (mm)	Width (max mm)
2B – Cold rolled, heat treated, pickled, skin passed plate	0.25–8.0	2032
2D – Cold rolled, heat treated, pickled plate	0.4–6.35	1524
2E – Cold rolled, heat treated, mechanically descaled plate	0.4–8.0	2032
2R – Cold rolled, bright annealed plate	0.25–3.5	1524
2H – Work hardened plate	0.4–6.35	1524
Polished, brushed plate	0.5–4.0	1524
