Alloy 600 Pipe

1. Standard: ASTM B163、ASTM B167、ASTM B474、AMS 5580
2. Diameters: 4.0 - 1219.2 mm
3. Wall thickness: 0.5 to 20mm
4. Length: Single, Double Random & Cut Length
5. Grades: Inconel 600,2.4816,UNS N06600

Send Inquiry

Product Introduction

Alloy 600 pipe has excellent corrosion resistance to various corrosive media such as acids, alkaline solutions and chloride-containing environments. High temperature resistance up to 2000 degrees Fahrenheit. 2.4816 Inconel 600 exhibits excellent oxidation resistance at high temperatures and is suitable for use in furnaces and heat exchangers, for example.

Nickel 600 pipe standard:

ASTM B163 Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes

ASTM B167: Standard Specification for Nickel- Chromium-Iron Alloys (UNS N06600, N06601, N06603, N06690, N06693, N06025, N06045, and N06696) Seamless Pipe and Tube, Etc.

ASTM B474 Standard Specification for Electric Fusion Welded Nickel and Nickel Alloy Pipe

2.4816 Alloy 600 Seamless Pipe Chemical Composition

Grade		C	Mn	Si	Fe	S	Cr	Cu	Ni
Inconel 600 Pipe	min.	–	–	–	6	–	14	–	72
Inconel 600 Pipe	max.	0.15	1	0.5	10	0.015	17	0.5	–

Inconel 600 Din 2.4816 Pipe Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min

Inconel 600 Pipe	Psi – 95,000 , MPa -655	Psi – 45,000 , MPa – 310	40

Inconel 600 Alloy Pipe Schedule and Wall Thickness

NOMINAL	O.D. INCHES	10S	40S & STD	80S & E.H.	160
1/8	0.405	0.049	0.068	0.095	-
1/4	0.54	0.065	0.088	0.119	-
3/8	0.675	0.065	0.091	0.126	-
1/2	0.84	0.083	0.109	0.147	0.187
3/4	1.05	0.083	0.113	0.154	0.218
1	1.315	0.109	0.133	0.179	0.25
1 1/4	1.66	0.109	0.14	0.191	0.25
1 1/2	1.9	0.109	0.145	0.2	0.281
2	2.375	0.109	0.154	0.218	0.343
2 1/2	2.875	0.12	0.203	0.276	0.375
3	3.5	0.12	0.216	0.3	0.437
3 1/2	4	0.12	0.226	0.318	-
4	4.5	0.12	0.237	0.337	0.531
4 1/2	5	-	0.247	0.355	-
5	5.563	0.134	0.258	0.375	0.625
6	6.625	0.134	0.28	0.432	0.718
7	7.625	-	0.301	0.5	-
8	8.625	0.148	0.322	0.5	0.906
9	9.625	-	0.342	0.5	-
10	10.75	0.165	0.365	0.5	1.125
11	11.75	-	0.375	0.5	-
12	12.75	0.18	0.375	0.5	1.312
14	14	0.188	0.375	0.5	1.406
16	16	0.188	0.375	0.5	1.593
18	18	0.188	0.375	0.5	1.781

Alloy 600 Seamless and Welded Pipe

Our 600 Alloy Pipe suppliers can provide Alloy 600 Welded Pipes or Seamless Pipes. Welded pipes are less expensive than seamless structure pipes. But welded pipes have longitudinal seams. If the highest corrosion resistance is required and can withstand higher pressures, ASTM B167 UNS N06600 seamless pipes are the best choice.
