Alloy 254SMO Plate
1. Standard: ASTM A240 / ASME SA240
2. Thickness: 4~100mm or as required
3. Width: 1000~3500mm or as required
4. Length: 2~12m or as required
Alloy 254SMO Plate is designed with an excellent chemical composition of Iron, Chromium, Nickel-Molybdenum, Nitrogen and Carbon. Designed for use in seawater and other corrosive chloride environments. SA 240 UNS S31254 has excellent resistance to pitting and crevice corrosion. This stainless steel plate has a PREN value of over 42.5. The melting point of Alloy 254 SMO material is in the temperature range of 1320℃ - 1390℃. We are a ALLOY 254 SMO supplier with 15+ export experience, contact us for more information and free quotes!
ASTM A240 UNS S31254 Plate Applications:
- Food Processing Equipment
- Desalination of Seawater
- Brine Treatment
- Chemical Processing Equipment
- Bleaching Equipment for Paper and Pulp Industry
SMO 254 / UNS S31254 Sheets & Plates Specifications
| Specifications | ASTM A240 / ASME SA240 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
SMO 254 / UNS S31254 Sheets & Plates Mechanical Properties
| Grade | SMO 254 |
|---|---|
| Density | 8.0 g/cm3 |
| Melting Point | 1320-1390 °C |
| Yield Strength (0.2%Offset) | 300 |
| Tensile Strength | 650 |
| Elongation | 35 % |
254 SMO vs 316 Stainless Steel
254 SMO Stainless Steel is a high-end austenitic grade with excellent nickel, molybdenum and chromium grades. 316 Stainless Steel is a standard austenitic grade with lower chemical content than 254 Smo grade.
Machining 254 SMO Stainless Steel
Due to its low sulfur content and extremely high work hardening rate, it is difficult to machine. However, machining techniques such as using overpowered machine tools, sharp tools, good lubrication, etc.
Welding SA 240 UNS S31254 Plate
UNS S31254 plate requires filler material, otherwise it will result in poor strength properties.
Heat Treatment Alloy 254SMO Plate
Annealing should be done at 1149-1204°C followed by water quenching.
